VRD4 Vacuum Pump

1. Excellent Performance
Integrated cylinder structure with higher precision. Proven rotary vane technology ensures more stable performance and greater reliability for the system.

2. Good Heat Dissipation
Air-cooled structure eliminates the need for an external water cooling unit, reducing system installation and maintenance costs.

Product Parameters：

Flow rate m³/h (L/s)	4
Power Supply	Single-phase electricity / Three-phase electricity
Motor power	400W
Limit partial pressure (vibration switch off) （Pa）	5 x 10(-2)
Limit total pressure (vibration switch off) (Pa)	5 x 10(-1)
Oil capacity	0.6-1L
Motor speed	1440 rmp
Operating ambient temperature	10-40℃
Noise	≤52Db
Weight	19kg

1. Excellent Performance

Integrated cylinder structure with higher precision. Proven rotary vane technology ensures more stable performance and greater reliability for the system.

2. Good Heat Dissipation

Air-cooled structure eliminates the need for an external water cooling unit, reducing system installation and maintenance costs.

3. Forced Lubrication

Built-in gear pump and constant pressure oil supply mechanism provide forced lubrication, ensuring stable and reliable operation even under high suction pressure.

4. Multi-Stage Vacuum Design

Meets varying vacuum requirements and water vapor handling capacities for different customers.

5. Dual Anti-Backflow Structure

Automatic anti-backflow valve more reliably protects your vacuum system from oil contamination after shutdown.

6. Fluororubber Seals

Enhances corrosion resistance and addresses oil leakage issues. Optional high-quality oil mist filter effectively filters oil mist, keeping the environment clean.
